IRF630

N-Channel, enhancement mode, silicon gate power field effect transistors

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.11~0.21 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.11~0.21

PartNumber:: IRF630

Brand:: International Rectifier - IR | Pack: TO | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Tony Tsai's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-03-11

From Other Seller

Part Number:IRF630
US $0.11 - 0.21
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IRF630 is N-Channel enhancement mode silicon gate power field effect transistors. It is advanced power MOSFETs designed, tested, and guaranteed to withstand a specified level of energy in the breakdown avalanche mode of operation. All of these power MOSFETs are designed for applications such as switching regulators, switching convertors, motor drivers, relay drivers, and drivers for high power bipolar switching transistors requiring high speed and low gate drive power. These types can be operated directly from integrated circuits. Formerly developmental type TA17412.

Parametrics

Absolute maximum ratings: (1)Drain to Source Voltage, VDSS: 200V; (2)Drain to Gate Voltage (RGS = 20kW), VDGR: 200V ; (3)Continuous Drain Current, ID: 9A; (4)TC = 100℃, ID: 6A; (5)Pulsed Drain Current, IDM: 36A; (6)Gate to Source Voltage, VGS: ±20V; (7)Maximum Power Dissipation, PD: 75W; (8)Linear Derating Factor: 0.6W/℃; (9)Single Pulse Avalanche Energy Rating, EAS: 150mJ; (10)Operating and Storage Temperature, TJ, TSTG: -55 to 150℃; (11)Maximum Temperature for Soldering, Leads at 0.063in (1.6mm) from Case for 10s, Tl: 300℃; (12)Maximum Temperature for Soldering, Leads at 0.063in (1.6mm) from Case for 10s, Tpkg: 260℃.

Features

Features: (1)9A, 200V; (2)r DS(ON) = 0.400W; (3)Single Pulse Avalanche Energy Rated; (4)SOA is Power Dissipation Limited; (5)Nanosecond Switching Speeds; (6)Linear Transfer Characteristics; (7)High Input Impedance; (8)Related Literature: TB334, Guidelines for Soldering Surface Mount Components to PC Boards.
